SPECIFICATIONS
Audio Sections
Front Left & Right
Rated Continuous Power Output/Channel (1 channel driven into 8 Ohms) 130 Watts, 20Hz to 20kHz
Rated Continuous Power Output/Channel (2 channels driven into 8 Ohms) 100 Watts, 20Hz to 20kHz
THD (at rated power) <0.05%
Rated Continuous Power Output/Channel (2 channels driven into 4 Ohms) 160 Watts <0.1% @ 1kHz
Center
Rated Continuous Power Output/Channel (1 channel driven into 8 Ohms) 130 Watts, 20Hz to 20kHz
Rated Continuous Power Output/Channel (1 channel driven into 8 Ohms) 100 Watts, 20Hz to 20kHz
THD (at rated power) <0.05%
Rated Continuous Power Output/Channel (2 channels driven into 4 Ohms) 160 Watts <0.1% @ 1kHz
Surround Left & Right
Rated Continuous Power Output/Channel (1 channel driven into 8 Ohms) 130 Watts, 20Hz to 20kHz
Rated Continuous Power Output/Channel (2 channels driven into 8 Ohms) 100 Watts, 20Hz to 20kHz
THD (at rated power) <0.05%
Rated Continuous Power Output/Channel (2 channels driven into 4 Ohms) 160 Watts <0.1% @ 1kHz
Surround Back Left & Right
Rated Continuous Power Output/Channel (1 channel driven into 8 Ohms) 130 Watts, 20Hz to 20kHz
Rated Continuous Power Output/Channel (2 channels driven into 8 Ohms) 100 Watts, 20Hz to 20kHz
THD (at rated power) <0.05%
Rated Continuous Power Output/Channel (2 channels driven into 4 Ohms) 160 Watts <0.1% @ 1kHz
Damping Factor > 100, all channels
Input Sensitivity (For rated power @ max VC) 250 mV Line IN
Input Impedance (Source Inputs) 47 K Ohms Line IN
Input Overload (Source Inputs) > 5 V Line IN
Output Voltage (Audio 1 and 5 OUTS) 250 mV
Output Voltage (Zone 2 Pre-Outs w/250 mV @ Source Inputs) 1.25V, VC Max.
Output Impedance (Pre-Outs) < 300 Ohms
Frequency Response (@ 1 Watt @ 8 Ohms) 10 Hz to 80 kHz
+
⁄- 1.5 dB
Channel Separation > 50 dB @ 10 kHz
Cross Talk Between Sources > 80 dB @ 10 kHz
S/N Ratio (Re: Rated Output, IEC A, Line Inputs 1k Ohm) > 110 dB (VC 20 dB below FCW)
Bass Control Range +/- 10 dB @ 100 Hz
Treble Control Range +/- 10 dB @ 10 kHz
Video Sections
Composite
Bandwidth 5 Hz to 10 MHz, +0dB, -3dB
Input/Output Levels 1.0V p-p
Input/Output Impedance 75 Ohms
S-Video
Bandwidth 5 Hz to 10 MHz, +0dB, -3dB
Input/Output Levels (Y) 1.0V p-p, 75 Ohms
Input/Output Levels (C) 0.286V p-p, 75 Ohms
Component
Bandwidth 5 Hz to 100 MHz, +0dB, -3dB
Input/Output Levels (Y) 1.0V p-p, 75 Ohms
Input/Output Levels (Pb/Cb) 0.7V p-p, 75 Ohms
Input/Output Levels (Pr/Cr) 0.7V p-p, 75 Ohms
