User Manual
93
7.1 Setting Motion Detection
Steps:
1. Enter Motion Detection interface and choose a camera you want to set motion detection.
Menu> Camera> Motion
Figure'8.1'Motion'Detection'Setup'Interface
'
2. Set motion detection area and sensitivity.
1) Check the checkbox of Enable Motion Detection to enable motion detection, use the mouse to
draw detection area(s) and drag the sensitivity bar to set sensitivity. Please refer to Chapter 5.3
Configuring Motion Detection Record.
Note: By default, the motion detection is configured in full screen.
2) Click the icon of Settings to set alarm response actions.
Figure'8.2'Set'Detection'Area'and'Sensitivity
'
3. Click Trigger Channel tab and select one or more channels which will start to record or become
full-screen monitoring when motion alarm is triggered.
To Next Page
