13. Place 2nd rotor half (5) on drive axle in dosing head with "This side
DOWN" surface being located first - the rollers must point towards
the recesses for the hydraulic connectors.
14. Insert hose (4) in dosing head (5) and snap the two hydraulic con‐
nectors into place - round side in dosing head (5).
15. Press the Clickwheel.
ð
The rotor turns slowly and the following appears:
‘ Please wait!’
.
The rotor stops and
‘Insert rotor again!’
appears.
16. Re-insert 1st rotor half (3) - the surfaces of the two rotor halves
must be perfectly flush.
17. Press the Clickwheel.
ð
The rotor turns and the following appears:
‘Please wait...’
.
The rotor stops and
‘Install Cover again!’
appears.
18. Place bearing cover (1) on dosing head (6).
19. Initially only loosely screw all 4 star screws (2) into dosing head (6).
20. Manually tighten the 4 star screws (2).
21. Press the Clickwheel.
ð
‘Run in tube?’
appears.
‘Yes’
/
‘No’
22. Selecting
[No]
exits this macro.
23.
You can return to the continuous display by pressing the
key.
If the dosing direction is also to be reversed, this can be
done by going to ‘Settings
è
Dosing direction
è
...’.
Assembly
25
