ProMinent gamma/ X Supplementary Operating Instructions

Index Sub Name Type Description Categ.* Attr
10h Auxiliary device alarm
codes 1
U32 MANDA RO
11h Auxiliary device alarm
codes 2
U32 MANDA RO
12h Auxiliary device alarm
codes 3
U32 MANDA RO
Index Sub Name Type Description Categ.* Attr
6003h 00h
HighestSubIndex
U32 Specific physical
units
MANDA RO
01h Physical unit pres‐
sure
U32 Standard: bar
0x004E0000,
gal (AE)
MANDA RW
6005h 00h
HighestSubIndex
GenericPump con‐
trol
MANDA
01h Generic pump com‐
mands
U8 Bit#0: Pump opera‐
tion: off=0 / on=1
MANDA RW
Bit#1: ResetFault:
No reset=0 / Reset
of fault=1
Bit#2: RemoteAc‐
cessReq: No
remote=0; Remote
access=1
Bit#3 to 7 Reserved
6007h 00h
HighestSubIndex
Identification MANDA RO
01h ManufacturerID String MANDA RO
02h DeviceType String MANDA RO
03h ProfileRevision String MANDA RO
Index Sub Name Type Description Categ.* Attr
6026h 00h
HighestSubIndex
Error notification
control
MANDA CO
02h Name String MANDA RW
03h Class String MANDA RW
07h NotificationCode U16 OPTION RW
6027h 00h
HighestSubIndex
Error notification
status
MANDA
01h Status U8 MANDA RO
Supplementary Operating Instructions CANopen
33

ProMinent gamma/ X Specifications

General

Protection class	IP65
Max. Pressure	25 bar
Power supply	100-230 V, 50/60 Hz
Material of pump head	PVDF, Stainless steel
Temperature range	-10 °C to +45 °C
Type	Diaphragm dosing pump
Stroke length	Adjustable
Stroke frequency	max. 180 strokes/min
Materials in contact with the medium	PVDF, PTFE, stainless steel
Control	Manual, external control via contacts or 0/4-20 mA signal
Control Options	External, potential-free contacts, 0/4-20 mA
Dosing Accuracy	±2%
