ProMinent gamma/ X Supplementary Operating Instructions

Bit positions Meaning
6 Internal error
5 Warning (e.g. container filling
level)
4 Suction active
3 Lowerer (only in ProMinent sys‐
tems)
2 Calibration invalid
1 Memory metering
0 (LSB) No remote operation possible
The object 'DeviceControl' is used to specify the operating mode
more precisely.
Tab. 20: DeviceControl BitValues
Bit positions Meaning
7 (MSB) Must be set to 0
6 Reset
5 Must be set to 0
4 -
3 Calibration completed
2 Must be set to 0
1 Batch memory active
0 (LSB) Must be set to 0
If Bit 6 (RESET) is set to ‘1’, the pump is stopped (DeviceMode =
0x00), existing errors are deleted and the batch memory is set to 0.
The object 'DeviceMode' is used to configure CANopen operating
mode of the pump.
Tab. 21: DeviceMode BitValues
Bit positions Meaning
7 (MSB) Must be set to 0
6 Must be set to 0
5 Must be set to 0
4 Must be set to 0
3 Must be set to 0
2 Must be set to 0
1 Continuous operation [0], batch
operation [1]
0 (LSB) Stop [0] / Start [1]
DeviceControl [Index 0x2A11, Sub‐
index 0x00]
DeviceMode [Index 0x2A12, Subindex
0x00]
Supplementary Operating Instructions CANopen
37

ProMinent gamma/ X Specifications

General

Protection class	IP65
Max. Pressure	25 bar
Power supply	100-230 V, 50/60 Hz
Material of pump head	PVDF, Stainless steel
Temperature range	-10 °C to +45 °C
Type	Diaphragm dosing pump
Stroke length	Adjustable
Stroke frequency	max. 180 strokes/min
Materials in contact with the medium	PVDF, PTFE, stainless steel
Control	Manual, external control via contacts or 0/4-20 mA signal
Control Options	External, potential-free contacts, 0/4-20 mA
Dosing Accuracy	±2%
