ProMinent gamma/ X Supplementary Operating Instructions

Reg‐
ister
Description Type Display / purpose
GMXa
1217 Metering time for batch U16 Min-/max values are also controlled by specifying
the "Metering time for batch"
1 … 10,000 sec
X
1219 Contact factor U16 Step-downs also possible for each contact
detected
0.01 … 99.99 strokes / contact
X
1221 Metering volume per contact
mode triggered
FLOAT
32
Specification for contact mode
0.00 001 … 99.99 l / contact
X
1223 Auxiliary capacity FLOAT
32
Dependent on
- dosing head fitted
- device context (e.g. adjusted suction stroke)
- …
X
1225 Activate concentration mode BOO‐
LEAN
0 - INACTIVE
1 - ACTIVE
X
1226 "Desired concentration" con‐
centration mode
FLOAT
32
0.01 … 100,000 ppm X
1228 Operating mode BOO‐
LEAN
GMXa and GXLa:
0 - AUTOMATIC OFF MODE
1 - AUTOMATIC ON MODE
Peristaltic pumps:
0 - AUTOMATIC ON (specified in litres)
1 - AUTOMATIC OFF (specified in revolutions)
X
1229 Target operating mode Enum 0 - EXTERNAL HALT
1 - MANUAL
2 - CONTACT
3 - BATCH
4 - ANALOGUE
X
1230 Target sub-operating mode Enum 0 = NO SUB-OPERATING MODE
1 - PRIMING
2 - AUXILIARY MODE
3 - BATCH TIME CONTROL
4 - BATCH GANGLINIE
5 - BATCH ANALOGUE-CONTROLLED
VOLUME
6 - BATCH ANALOGUE-CONTROLLED FRE‐
QUENCY
7 - BLEEDING
8 - CALIBRATION
X
Supplementary Operating Instructions for Modbus RTU
55

ProMinent gamma/ X Specifications

General

Protection class	IP65
Max. Pressure	25 bar
Power supply	100-230 V, 50/60 Hz
Material of pump head	PVDF, Stainless steel
Temperature range	-10 °C to +45 °C
Type	Diaphragm dosing pump
Stroke length	Adjustable
Stroke frequency	max. 180 strokes/min
Materials in contact with the medium	PVDF, PTFE, stainless steel
Control	Manual, external control via contacts or 0/4-20 mA signal
Control Options	External, potential-free contacts, 0/4-20 mA
Dosing Accuracy	±2%
