ProMinent gamma/ X Supplementary Operating Instructions

Reg‐
ister
Description Type Display / purpose
GMXa
1410 "Stroke rate 1st user-defined
point" analogue input
UINT16 For the analogue operating modes - LINEAR
CURVE - LOWER SIDE BAND - UPPER SIDE
BAND this parameter determines the stroke rate
for the first support point of the "Current <->
stroke rate" assignment lines. Setting in Auto Off
operating mode only
0 … [max. stroke rate] strokes/h
X
1411 "Capacity 1st user-defined
point" analogue input
FLOAT
32
For the analogue operating modes - LINEAR
CURVE - LOWER SIDE BAND - UPPER SIDE
BAND this parameter determines the metering
rate for the first support point of the "Current <->
capacity" assignment lines. Setting in Auto On
operating mode only
0 … [max. capacity] l/h
X
1413 "Current 2nd user-defined
point" analogue input
FLOAT
32
For the analogue operating modes - LINEAR
CURVE - LOWER SIDE BAND - UPPER SIDE
BAND this parameter determines the current
value for the second support point of the "Current
<-> stroke rate/capacity" assignment lines
0.0 … 20.0 mA
X
1415 "Stroke rate 2nd user-defined
point" analogue input
UINT16 For the analogue operating modes - LINEAR
CURVE - LOWER SIDE BAND - UPPER SIDE
BAND this parameter determines the stroke rate
for the first support of the "Current <-> stroke rate"
assignment lines. Setting in Auto Off operating
mode only
0 … [max. stroke rate] strokes/h
X
1416 "Capacity 2nd user-defined
point" analogue input
FLOAT
32
For the analogue operating modes - LINEAR
CURVE - LOWER SIDE BAND - UPPER SIDE
BAND this parameter determines the metering
rate for the second support of the "Current <->
capacity" assignment lines. Setting in Auto On
operating mode only
0 … [max. capacity] l/h
X
1418 "Fault message current too
high" analogue input
BOO‐
LEAN
0 - DO NOT REPORT FAULT
1 - REPORT FAULT
X
1419 "Fault message current too
low" analogue input
BOO‐
LEAN
0 - DO NOT REPORT FAULT
1 - REPORT FAULT
X
1420 "Lower user-defined error limit
current" analogue input
FLOAT
32
For the analogue operating modes - LINEAR
CURVE - LOWER SIDE BAND - UPPER SIDE
BAND this parameter determines the configurable
lower fault threshold for the input current. Setting
only effective if "Fault message current too low"
parameter was set to "active"
0.1 … 20.5 mA
X
Supplementary Operating Instructions for Modbus RTU
58

ProMinent gamma/ X Specifications

General

Protection class	IP65
Max. Pressure	25 bar
Power supply	100-230 V, 50/60 Hz
Material of pump head	PVDF, Stainless steel
Temperature range	-10 °C to +45 °C
Type	Diaphragm dosing pump
Stroke length	Adjustable
Stroke frequency	max. 180 strokes/min
Materials in contact with the medium	PVDF, PTFE, stainless steel
Control	Manual, external control via contacts or 0/4-20 mA signal
Control Options	External, potential-free contacts, 0/4-20 mA
Dosing Accuracy	±2%
