ProMinent gamma/ X Supplementary Operating Instructions

Modul
e/slot
Index Name Modul
e
name
Diag.
numbe
r
Identi‐
fication
(hex)
Type Data‐
flow *
Description
bit Name Function
2 Mode 00 – stop
03 – contact
3 01 – manual
04 – analogue
4 02 – batch
5 Fault There are faults
- see "Fault"
6 Warn‐
ings
There are warn‐
ings - see
"Warnings"
7 Hand
stop
Pump has been
stopped man‐
ually
8 Stop Pump has
stopped
9 Pri‐
ming
Pump is in pri‐
ming mode
(higher-level
function)
10 Auxil‐
iary
Pump is in aux‐
iliary mode
(higher-level
function)
11 Pause Pump has been
switched to
‘Pause’ status
(higher-level
function)
12 Modul
e
Fieldbus active
13 Flow Metering mon‐
itor is activated
14 Batch-
Mem.
Batch memory
is activated
15 Cali‐
brated
Pump is cali‐
brated
16 - -
17 - -
18 - -
19 Dia‐
phrag
m rup‐
ture
Diaphragm rup‐
ture indicator is
installed
20 Con‐
centra‐
tion
Concentration
calculation is
activated
Supplementary Operating Instructions PROFIBUS
®
71

ProMinent gamma/ X Specifications

General

Protection class	IP65
Max. Pressure	25 bar
Power supply	100-230 V, 50/60 Hz
Material of pump head	PVDF, Stainless steel
Temperature range	-10 °C to +45 °C
Type	Diaphragm dosing pump
Stroke length	Adjustable
Stroke frequency	max. 180 strokes/min
Materials in contact with the medium	PVDF, PTFE, stainless steel
Control	Manual, external control via contacts or 0/4-20 mA signal
Control Options	External, potential-free contacts, 0/4-20 mA
Dosing Accuracy	±2%
