ProMinent gamma/ X Supplementary Operating Instructions

Index Name Explanation
0x08 SetpointOperation Operating mode
0=Continuous;
1= Batch;
2=External contact;
3=Analogue
0x09 ActualOperation Operating mode 0=continuous;
1= Batch;
2=External contact;
3=Analogue
0x0A SetpointFactor Batch size in batch metering oper‐
ating mode transmission ratio
*100 in "external contact" oper‐
ating mode
0x0B ActualFactor Batch size in batch metering oper‐
ating mode transmission ratio
*100 in "external contact" oper‐
ating mode
0x0C SetpointMetfrequency Max metering frequency in "con‐
tinuous" operating mode max.
metering frequency in "batch"
operating mode and "ext. Contact"
operating modes
0x0D ActualMetfrequency Max metering frequency in "con‐
tinuous" operating mode max.
metering frequency in "batch"
operating mode and "ext. Contact"
operating modes
0x0E Actualfrequency Actual frequency. The number of
strokes actually metered by the
pump. In "batch" and "ext. con‐
tact" the metering frequency is
displayed
0x0F Stroke length Adjusted stroke length in % from
end stop
0x10 Remaining strokes The number of strokes still to be
performed in batch metering in
progress
0x11 Fault Fault sources flags - see below
0x12 Warning Warning sources flags - see below
0x13 MaxFrequency Maximum frequency in strokes /
min that can be metered
0x14 Number of strokes Number of strokes performed
since the last reset
0x15 LpH Number of strokes performed
since the last reset
0x16 Quantity Metered volume in litres (gallons)
since the last reset
Supplementary Operating Instructions PROFIBUS
®
85

ProMinent gamma/ X Specifications

General

Protection class	IP65
Max. Pressure	25 bar
Power supply	100-230 V, 50/60 Hz
Material of pump head	PVDF, Stainless steel
Temperature range	-10 °C to +45 °C
Type	Diaphragm dosing pump
Stroke length	Adjustable
Stroke frequency	max. 180 strokes/min
Materials in contact with the medium	PVDF, PTFE, stainless steel
Control	Manual, external control via contacts or 0/4-20 mA signal
Control Options	External, potential-free contacts, 0/4-20 mA
Dosing Accuracy	±2%
