Figure 1. SmartStor NS4300N Front View
Figure 2. SmartStor NS4300N Rear View
Disk Drive
Drive Carrier
Disk Activity
LED
Power Button
Ethernet
Activity LED
One Touch
Backup Button
Disk Status
LED
Note: This SmartStor is shown without the front door.
System Status
LED
Power
Connection
USB
Connections
RJ45 Network
Connection
Disk Drive
Cooling Fan
Power
Supply Fan
