Configuration System Configuration
CubiScan 110-T 27
2. The configuration menu is displayed at the bottom of the screen. Select
the
Other option if it is not already selected.
Update Firmware Tap this button to update the firmware.
The field below the button displays all firmware files that are saved on the
SD card. If you would like to update the CubiScan 110-T to a certain
firmware file, select it in the list displayed and tap
[Update Firmware].
Reset Tap this button to reboot the system and update the firmware. The system
must be rebooted each time the firmware is updated.
Date/Time This displays the current date and time.
Figure 20
Configure Ethernet
To Next Page
