Communications Protocol Ethernet (TCP/IP) Cable Pin Assignments
CubiScan 110-T 55
Ethernet (TCP/IP) Cable Pin Assignments
The CubiScan 110-T Ethernet port uses the 10/100Base-T TCP/IP
communications protocol. The following table shows the Ethernet RJ-45
connector pin assignments.
USB Port Cable Pin Assignments
The USB port is configured as a HID device. VID = 0x1FC9, PID = 0x0081.
The CubiScan 110-T includes a USB 2.0 type B connector, as shown below.
Data Bits 8
Start Bits 1
Stop Bits 1
Asynchronous
Communication
Parameters
RJ-45 Connector Pin Assignments
Pin Signal Description
1 TD+ Transmit Data
2 TD- Transmit Data
3 RD+ Receive Data
4 NC No Connection
5 NC No Connection
6 RD- Receive Data
7 NC No Connection
8 NC No Connection
