Communications Protocol CubiScan 110-T Command Set
CubiScan 110-T 59
Calibrate
Dimensions:
Causestheinstrumenttoenterthedimensioncalibrationroutine.Eachtime
thiscommandissent,theinstrumentpromptstheoperatortofollowa
definedcalibrationpattern.
Command
Description
Command
Packet
Acknowledge
Description
Acknowledge
Packet
Nack
Description
Neg.Ack.
Packet
StartByte
<STX>
StartByte
<STX>
StartByte
<STX>
Command
(D)
Command
(D)
Command
(D)
Ack
(A)
Nack
(N)
Identifier
(00)‐(99)
EndBytes
<ETX><CR><LF>
EndBytes
<ETX><CR><LF>
EndBytes
<ETX><CR><LF>
Length
5
Length
8
Length
6
Identifiers
01CleartheCubiScan
02Place12”TargetfacingLEFT
03Place12”TargetfacingRIGHT
04Place12”TargetfacingUP
05DimensionCalibrationComplete
CalibrateScale:
Causestheinstrumenttoenterthescalecalibrationroutine.Eachtimethis
commandissent,theinstrumentpromptstheoperatortofollowadefined
calibrationpattern.
Command
Description
Command
Packet
Acknowledge
Description
Acknowledge
Packet
Nack
Description
Neg.Ack.
Packet
StartByte
<STX>
StartByte
<STX>
StartByte
<STX>
Command
(S)
Command
(S)
Command
(S)
Calibration
Weight
(025.00)–
(201.00)
Ack
(A)
Nack
(N)
Identifier
(00)‐(99)
EndBytes
<ETX><CR><LF>
EndBytes
<ETX><CR><LF>
EndBytes
<ETX><CR><LF>
Length
11
Length
8
Length
6
Identifiers
01CleartheCubiScan
02PlaceTestWeight
03ScaleCalibrationComplete
DimensionUnits:
Causestheinstrumenttochangethecurrentdimensionunitstoeitherinches
orcentimeters.
Command
Description
Command
Packet
Acknowledge
Description
Acknowledge
Packet
Nack
Description
Neg.Ack.
Packet
