Communications Protocol CubiScan 110-T Command Set
CubiScan 110-T 82
0275
SensorMsrTestInvalids0.00‐
Width
Unsigned
Int 5 0 x x x
0276
SensorMsrTestInvalids12.00‐
Width
Unsigned
Int 5 0 x x x
0277
SensorMsrTestInvalids24.00‐
Width
Unsigned
Int 5 0 x x x
0278
SensorMsrTestInvalids0.00‐
Height
Unsigned
Int 5 0 x x x
0279
SensorMsrTestInvalids12.00‐
Height
Unsigned
Int 5 0 x x x
Read/WriteValueTableDefinition
Number VariableName Type
Total
Length
Mantissa
Length
100‐
T
110‐
T
150‐
T
0280
SensorMsrTestInvalids24.00‐
Height
Unsigned
Int 5 0 x x x
0281
SensorMsrTestInvalids36.00‐
Height
Unsigned
Int 5 0 x x x
0282 GateLimitRight‐CubiScan25
Unsigned
Int 4 0
0283 GateLimtLeft‐CubiScan25
Unsigned
Int 4 0
0284 GateFilterType‐All,Etc.
Unsigned
Int 1 0
0285 SensorLength1OverallGain
Unsigned
Int 5 0 x x x
0286 SensorWidthOverallGain
Unsigned
Int 5 0 x x x
0287 SensorHeightOverallGain
Unsigned
Int 5 0 x x x
0288 SensorLength2DBW Float 4 1 x x
0289 SensorLength2CPI Float 4 0 x x
0290 SensorLength2Blank Float 4 2 x x
0291 SensorLength2Gain Float 4 1 x x
0292 SensorLength2Pulse Float 2 0 x x
0293 SensorLength2Delay Float 3 0 x x
0294 SensorLength2OverallGain
Unsigned
Int 5 0 x x
0295 BarcodeEnable
Unsigned
Int 1 0 x x x
0296 PrinterEnable
Unsigned
Int 1 0 x x x
