Troubleshooting
MOTOR (NR) RPM
TOO HIGH OR TOO
LOW
Error during arming. Please make sure that the UAV is aligned horizontally during arming.
REAR TILT
MALFUNCTION!
Occurs when hardware is defec-
tive or there is a tilt mechanismus
malfunction
1. Automatic Retransition and Landing is initiated
2. Do not y! Contact your sales agent.
RTR TOO FAR AWAY The retransition waypoint is too far
away from the take-off position.
1. Locate the retransition waypoint closer to the home waypoint (see chapter 8.2.3).
2. Write mission to UAV again (see chapter 8.1.2).
3. Repeat the preight check.
SD CARD ERROR An error with the autopilot SD
card occured during the preight
check.
1. Disconnect the battery from the UAV and connect it again.
2. Repeat the preight check.
SENSOR ERROR A sensor error occured during the
preight check.
1. Disconnect the battery from the UAV and connect it again.
2. Repeat the preight check.
SENSOR INIT
ERROR
Error during the sensors initiali-
zation.
1. Disconnect the battery from the UASand connect it again.
2. Turn on the UASagain.
TOO MANY
WAYPOINTS
Too many Waypoints Please adjust the number of waypoints. It is limited to 200.
TRANSITION
AIRSPEED TOO LOW
The airspeed could build up
during transition.
Possible reasons are a transition
in tail wind or a blocked airspeed
sensor tube.
The transition is aborted and an automatic hover to Base is initiated.
Contact your Quantum-Systems sales agent in case the transition was correctly plan-
ned into the wind.
WIND SPEED /
WIND TOO STRONG
The wind is too strong either du-
ring launch or in-ight.
Launch: The UAV will abort the mission and returns to the launch point.
In-Flight: If reaching 12 m/s, an automatic Come Home is initiated.
