TROUBLESHOOTING
8-3
Key
Action
Parameter Display
Raw Reading 1A 167 (+ = 10X)
[MODE] Raw Reading 10A 188 (+ = 100X)
[Y/+] Raw Reading 100A 310
[MODE] Raw Reading 1B 165 not used (+ = 10X)
[MODE] Raw Reading 10B 166 not used (+=100X)
[Y/+] Raw Reading 100B (+=100X)
[MODE] Lamp Current Lamp = 143
[MODE] Lamp Fail Level Fail = 103 (+/-)
[MODE] Lamp Drive
Ldrv = 175 (+/-)
#
[MODE] Battery Type Ni-Cd/MH /Alkaline
[MODE] LCD Contrast
Contrast (+/-)
----
[MODE] Battery Duration Battery Duration: XX:XX
[MODE] Pump Current Pump 7/ 7
[MODE] Pump Stall Level Stall 10 (+/-)
[MODE] Pump Motor drive Mdrv = 250 (+/-)*
[MODE] DAC Output Count DAC = 2048 (+/-)
[MODE] Alarm Test Alarm (on/off)?
[MODE] Ambient Light
Level
Lite = 237
[MODE] Backlight Trip
Level
Trip = 100 (+/-)
[MODE] PC Comm PC Comm?
Table 8-1 Diagnostic Mode Menu
Notes: * Do not change this setting.
#
The value for 9.8 eV and 11.7 eV lamps is 200, and
for 10.6 eV is 175. Normally, this setting should not
be changed.
