COMPUTER INTERFACE
5-16
5.5.2 Send Configuration to the
MiniRAE 2000
After the configuration data file is opened by the
ProRAE-Suite software, the user can send the
configuration settings to the MiniRAE 2000 monitor. To
send the configuration settings to the instrument, click
Communication->Send Config menu item or click the
Send toolbar icon (right arrow with “Send” letters), a
message box will appear to remind the user to connect the
instrument to the PC through the serial port. After making
sure that the instrument is connected to the PC and ready
for communication, click the OK button to start the data
transfer.
After the configuration information is sent successfully, a
message box will appear to indicate that the configuration
sending process is completed. Click the OK button to
close the message box.
If the communication is not successful, an error message
indicating that there is no response from the instrument
will appear. Check the cable to make sure that the
connectors on both ends of the cable are securely seated
in the sockets and the unit is set to communication ready
mode, then try to send the configuration again. If the
error message still appears after repeated attempts, call an
authorized service center for help.
