COMPUTER INTERFACE
5-18
5.5.4 Configuring All Settings
A user can use this function to update the entire
configuration settings (except the instrument ID, serial
number and the datalog option) in the MiniRAE 2000
monitor. To configure all the settings in the instrument,
click the Option->Config All menu item, and a message
box will appear to remind the user to connect the
instrument to the PC through the serial port. After making
sure that the instrument is connected to the PC, click the
OK button. Another message box will appear to warn the
user that this operation will erase all the current
configuration settings in the monitor. If the user does not
want this to happen, click the Cancel button, otherwise
click the OK button to start the data transfer.
After the information is sent successfully, a message box
will appear to indicate that the sending configuration
process is completed. Click the OK button to close the
message box.
Warning: The Config All option is mainly used to
restore the MiniRAE 2000 monitor’s default operational
settings when the configuration of the unit is non-
recoverable and the unit is malfunctioning. Because the
default parameters are not normally fit a specific unit, a
user will need to re-calibrate, re-set lamp and pump
thresholds, re-set LCD contrast, etc. Try not to use this
function if possible.
