OPERATION
2-11
Note: Before datalogging can be turned on, this function
must be enabled as described in Section 4.6.4.
• PC COMMUNICATION: Allows the user to upload
data from the MiniRAE 2000 to a Personal Computer
(PC) or send/receive configuration information between
a PC and the MiniRAE 2000. Connect the monitor to a
serial port of a PC, and start the MiniRAE 2000
application software. Press the [Y/+] key and the LCD
displays “pause monitor, ok?” Press the [Y/+] key one
more time, the display shows “Comm...” The monitor
is now ready to receive commands from the PC.
• CURRENT OPERATING MODE: The monitor
displays the current operating mode e.g.; “Survey”, the
site ID, gas name and then returns to “Ready..”
To choose a specific display, press the [MODE] key one or
more times until the desired display appears.
Taking a measurement:
There are two ways to start a measurement. 1) Operating in
Hygiene mode. 2) Manually start and stop measurement in
Survey mode. To start a measurement in Hygiene mode,
please refer to Section 4.7.1 on “Change Op mode”. To
start a measurement in Survey mode, the MiniRAE 2000
monitor must first be in the “Ready…” mode. This is the
mode to which the monitor normally powers up.
Measurement phases:
• Ready
• Start measurement
• Measurement Display and datalogging
• Stop measurement
