Rain Bird LXME2 User Manual

Current Section: Setup 18 Navigation:
1 Turn the dial to Setup
2 At the SETUP screen, with “Master Valves” selected, press Next .
3 At the Master Valve Setup screen, press the and keys to select the desired Master
Valve press Next to make your selection.
•
MV/P 02 can only be used on models
SETUP
Next
Master Valves
Weather Sensors
Station Setup
Flow Sensors
Advanced Station Settings
Master Valve Setup
MV
Next
01
Master Valve Setup
MV/P
Next
02
MV01 - (NCMV or NOMV Setup)
1 Use the & buttons to choose between a normally open (NOMV) or normally closed
(NCMV) master valve to match your system conguration. Then press Next .
•
If your system does not have a master valve then select “Unused” and press Next.
2 Select the number of valves that the MV will control (1 or 2).
•
Setting the number of valves to 2 will not control the valves individually, it will only adjust the output voltage
to ensure both valves open.
