Setup 24
Navigation:
Single Flo
w Sensor Installation Example
Dual Flo
w Sensor I
nstallation Example
Flow Sensor 1
Flow Sensor 2 (
Optional, see note below)
•
T
o measure ow from 2 w
ater sources a device that scales the signals fr
om two ow sensors and combines
them into one digital output is needed. Use C
ombiow CBF-100-00 or equiv
alent.
23
25
