ISCOM6820-GP (A) Hardware Description
2 Components
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
10
Parameter
Description
Baud rate
115200 baud
Cable specifications
4-core shielded cable
Table 2-5 lists parameters of the SNMP interface.
Table 2-5 Parameters of the SNMP interface
Parameter
Description
Connector
RJ45
Interface rate
10/100/1000 BASE-T auto-negotiation
Wiring
Support adaption to straight-through/crossover cable in host mode
Compliance
standard
IEEE 802.3
2.2.4 LEDs
There are 4 LEDs on the MCUA card, where 2 LEDs are integrated with the 10GE Ethernet
optical interface.
Table 2-6 lists LEDs on the MCUA card.
Table 2-6 LEDs on the MCUA card
LED
Status
Description
ACT
Green

On: the card is the active card.

Off: the card is the backup card.
SYS/ALM
Three
colors
System working LED

Blinking green every 1s: the card works normally.

Blinking green every 0.25s: the card is initiating and
loading.

Red (On): the system fails (the backplane fails).

Red (Off): the card is not properly inserted.

Orange (On): the card is in Standby mode.

Orange (Off): the system works abnormally.
LINK/ACT
1/2
(SFP+ optical
interface)
Green
Line working LED

Green: the interface is connected properly.

Blinking green: the interface is transmitting data.

Off: the interface is disconnected or connected
improperly.
