Raisecom ISCOM6820-GP User Manual

Raisecom
ISCOM6820-GP (A) Hardware Description
3 Fiber and cables
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
31
Parameter
Description
Certification
CCC
RoHS
Compliant
Customized length
Supported, the cable length is D.
3.5 AC power cable
3.5.1 Introduction
The AC power cable supplies 110/220 VAC power from the power souring equipment to the
power interface on the RPA0601 module of the ISCOM6820-GP, and then transmits power to
the entire device.
Types of the AC power cable of the ISCOM6820-GP depend on different regional standards,
as shown in Table 3-10.
Table 3-10 AC power cable of the ISCOM6820-GP
Regional standard
Name
European standard
POL-AC-European 3-pin/C13 connector-0.75 mm
2
-D/RoHS
American standard
POL-AC-American 3-pin/C13 connector-18AWG-D/RoHS
3.5.2 Appearance
The AC power cable which meets European standard is composed of a European French
mode 3-pin plug and a C13 connector, as shown in Figure 3-10.
Figure 3-10 European AC power cable
The AC power cable which meets American standard is composed of an American 3-pin plug
and a C13 connector, as shown in Figure 3-11.
