Raisecom ISCOM6820-GP User Manual

Raisecom
ISCOM6820-GP (A) Hardware Description
3 Fiber and cables
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
34
3.6.3 Technical specifications
Table 3-13 lists technical specifications of the ground cable.
Table 3-13 Technical specifications of the ground cable
Parameter
Description
Model
POL-ground cable-RNB22-6S/stripped wire-16mm
2
-D/RoHS
Standard
Comply with the UL standard and meet RoHS requirements.
Conducting wire
60227 IEC 02 (RV) yellow/green copper-core conducting wire 5
AWG (1 × 16mm
2
)
Stripped end
10 mm long, tinned
Cable length
4 m or customized, the D indicates the cable length which can be
customized. For example, if the customer requires a 2-m cable, the
cable name will be named POL-ground cable-RNB22-6S/stripped
wire-16mm2-2m/RoHS.
The letter D in the model indicates the length, which can be customized. For example,
if the customer requires 2-meter cables, they are named POL-ground cable-RNB22-
6S/stripped wire-16mm2-2m/RoHS.
Table 3-14 lists technical specifications of the OT terminal.
Table 3-14 Technical specifications of the OT terminal
Parameter
Description
Standard
RNB22-6S
Specifications

Inner diameter of soldering lug: 6.5 mm

Outer diameter of soldering lug: ≤ 12.2 mm

Inner diameter of sheath: 7.7 mm

Thickness of soldering lug: ≥ 1.9 mm
Section area of
conducting wire
5–4 AWG (16–25 mm
2
)

The ISCOM6820-GP is delivered without the ground cable. If required, prepare or
make the ground cable on site.

The ground cable cannot be longer than 30 m and should be as short as possible;
otherwise, a ground bar should be used.
