Raisecom
ISCOM6820-GP (A) Hardware Description
4 Pluggable optical modules
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
Table 4-4 Technical specifications of the SFP+ optical interface
Optical interface properties
Depend on the SFP+ optical module.
Table 4-5 lists technical specifications of the SFP+ optical module.
Table 4-5 Technical specifications of the SFP+ optical module
Tx
wavelength
(nm)
Laser type
Min.
overload
point
(dBm)
Transmiss
ion
distance
(km)
4.3 PON SFP optical module
4.3.1 Functions and appearance
The PON SFP optical module can be applied to the PON system. It is integrated with sending
and receiving features.
Figure 4-4 shows the appearance of the PON SFP optical module.
Figure 4-4 PON SFP optical module
4.3.2 Standard
The GPON interface on the ISCOM6820-GP supports the optical module compliant with the
Class B+, Class C+, and Class C++ standard.
