ISCOM6820-GP (A) Hardware Description
2 Components
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
12
Table 2-8 lists interfaces on the GPSC card.
Table 2-8 Interfaces on the GPSC card
Interface
Type
Usage
Description
PON 1–16
PON SFP
GPON service
interface
Available optical module type: Class
B+, Class C+, or Class ++
2.3.4 LEDs
There are 17 LEDs on the GPSC card.
Table 2-9 lists LEDs on the GPSC card.
Table 2-9 LEDs on the GPSC card
LED
Status
Description
SYS/ALM
Three
colors
System working LED

Blinking green every 1s: the card works normally.

Blinking green every 0.25s: the card is initiating and loading.

Red (On): the system fails (the backplane fails).

Blinking red: the card is not properly inserted.

Orange (On): the card is in Standby mode.

Orange (Off): the system works abnormally.
LNK 1–16
Green
PON interface working LED

Green: the PON interface is connected properly and there is a
registered ONU working on the interface.

Off: the PON interface is disconnected or there is no registered
ONU working on the interface.
2.3.5 Technical specifications
Table 2-10 lists technical specifications of the GPSC card.
Table 2-10 Technical specifications of the GPSC card
Parameter
Description
Dimensions
391.50 mm (Width) × 222 mm (Depth) × 22.56 mm (Height)
Weight
1.3 kg
Power consumption
< 70 W
