ISCOM6820-GP (A) Hardware Description
3 Fiber and cables
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
22
3 Fiber and cables
This chapter describes fiber and cables of the ISCOM6820-GP, including the following
sections:

Fiber

Ethernet cable

Configuration cable

DC power cable

AC power cable

Ground cable
3.1 Fiber
3.1.1 Introduction
The ISCOM6820-GP supports the Single-Mode Fiber (SMF) and Multi-Mode Fiber (MMF).
These two kinds of fiber are different in color. The yellow one is the single-mode fiber and
the orange one is the multi-mode fiber.
The ISCOM6820-GP can be connected to the Optical Distribution Frame (ODF) or optical
interfaces of other devices through fiber.
Table 3-1 lists the type and usage of the fiber.
Table 3-1 Type and usage of the fiber
Usage
Local connector
Remote connector
Type
Standard

Connect the ISCOM6820-
GP to the ODF through the
Ethernet optical interface.

Connect the Ethernet optical
interface on the
ISCOM6820-GP to optical
interfaces on other devices.
LC/PC
LC/PC
2 mm SMF
ITU-T G.652
2 mm MMF
LC/PC
FC/PC
2 mm SMF
2 mm MMF
LC/PC
SC/PC
2 mm SMF
2 mm MMF
