ISCOM6820-GP (A) Hardware Description
3 Fiber and cables
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
32
Figure 3-11 American AC power cable
3.5.3 Technical specifications
Table 3-11 lists technical specifications of the European AC power cable.
Table 3-11 Technical specifications of the European AC power cable
Parameter
Description
Name
POL-AC-European 3-pin/C13 connector-0.75 mm
2
-D/RoHS
Connector 1
European 3-pin plug
Connector 2
IEC60320-C13 connector
Cable
color
Inner
Black (PVC insulating layer)
Outer
Blue (N), brown (L), and yellow/green strip (E)
Conductor
gauge
3×0.75 mm
2
Length
The letter D indicates the length, which can be customized. For
example, if the customer requires 1.5-meter cables, they are named
POL-AC-European 3-pin/C13 connector-0.75 mm
2
-1.5 m/RoHS.
Table 3-12 lists technical specifications of the American AC power cable.
Table 3-12 Technical specifications of the American AC power cable
Parameter
Description
Name
POL-AC-American 3-pin/C13 connector-18AWG-D/RoHS
Connector 1
NMEA5-15 American 3-pin plug
Connector 2
IEC60320-C13 connector
Cable
color
Inner
Black (PVC insulating layer)
Outer
White (N), black (L), and yellow strip (E)
Conductor
gauge
18 AWG/3C
Length
The letter D indicates the length, which can be customized. For
example, if the customer requires 1.5-meter cables, they are named
POL-AC-American 3-pin/C13 connector-18AWG-1.5m/RoHS.
