Raisecom ISCOM6820-GP User Manual

Raisecom
ISCOM6820-GP (A) Hardware Description
5 Lookup table of LEDs
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
41
5 Lookup table of LEDs
Table 5-1 lists LEDs of the ISCOM6820-GP.
Table 5-1 LEDs of the ISCOM6820-GP
LED
Status
Description
PWR
Green
Power LED

Green: the power supply is working properly.

Off: the power supply is working improperly.
SYS
Green
System working LED

Fast blinking green (4 Hz): the system is initializing.

Slow blinking green (0.5 Hz): the system is working
properly.

Off: the system is working improperly.
LINK/ACT
(SFP optical
interface)
Green
Line working LED

Green: the interface is connected properly.

Blinking green: the interface is transmitting data.

Off: the interface is disconnected or connected
improperly.
LINK/ACT
(RJ45 electrical
interface
integrated LED)
Green
Line working LED

Green: the interface is connected properly.

Blinking green: the interface is transmitting data.

Off: the interface is disconnected or connected
improperly.
