ISCOM6820-GP (A) Hardware Description
5 Lookup table of LEDs
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
42
LED
Status
Description
SYS/ALM
Three
colors
System working LED

Blinking green every 1s: the card works normally.

Blinking green every 0.25s: the card is initiating and
loading.

Red (On): the system fails (the backplane fails).

Blinking red: the card is not properly inserted.

Orange (On): the card is in Standby mode.

Orange (Off): the system works abnormally.
When the card is in standby status (the orange LED
On), all other LEDs will be Off.
LNK
Green
PON interface working LED

Green: the PON interface is connected properly and there
is a registered ONU working on the interface.

Off: the PON interface is disconnected or there is no
registered ONU working on the interface.
ALM
Red
Power alarm LED

Red: the power is working improperly and an alarm is
generated.

Off: the power is working properly.
AC
Green
AC power working LED

Green: the power module is working properly.

Off: the power module is working improperly.
-48 V
Green
Output voltage status LED

Green: the DC voltage is output normally.

Off: the DC voltage is output improperly.
