Raisecom ISCOM6820-GP User Manual

Raisecom
ISCOM6820-GP (A) Hardware Description
2 Components
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
14
Table 2-12 LEDs on the GP16 subcard
LED
Status
Description
SYS/ALM
Three
colors
System working LED

Blinking green every 1s: the card works normally.

Blinking green every 0.25s: the card is initiating and loading.

Red (On): the system fails (the backplane fails).

Blinking red: the card is not properly inserted.

Orange (On): the card is in Standby mode.

Orange (Off): the system works abnormally.
When the card is in standby status (the orange LED On),
all other LEDs will be Off.
LNK 1–16
Green
PON interface working LED

Green: the PON interface is connected properly and there is a
registered ONU working on the interface.

Off: the PON interface is disconnected or there is no registered
ONU working on the interface.
2.4.5 Technical specifications
Table 2-13 lists technical specifications of the GP16 card.
Table 2-13 Technical specifications of the GP16 card
Parameter
Description
Dimensions
391 mm (Width) × 225 mm (Depth) × 22.16 mm (Height)
Weight
1.1 kg
Power consumption
70 W
2.5 Expansion service card (GE16)
2.5.1 Introduction
The GE16 card is the GE Ethernet service card of the ISCOM6820-GP, providing 16 GE
interfaces.
2.5.2 Panel and slots
The GE16 card can be inserted into slot 4 only.
Figure 2-11 shows the panel of the GE16 card.
