Raisecom
ISCOM6820-GP (A) Hardware Description
4 Pluggable optical modules
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
36
Figure 4-2 Label of the 1000 Mbit/s SFP optical module
Table 4-1 describes the model of the 1000 Mbit/s SFP optical module.
Table 4-1 Model of the 1000 Mbit/s SFP optical module
Field
Description
USFP
Internal identifier, indicating it is a universal SFP
Gb
Transmission rate: 1.25 Gbit/s
S1
Transmission distance:
M: 0.55 km
S1: 15 km
S2: 40 km
S3:80 km
D
Support DDM.
01
Internal identifier, different values of which indicate the same function
R
Comply with RoHS.
1310nm
Tx wavelength: 1310 nm
SM
SMF
DDM
Support link detection.
21CFR (J)
Comply with U.S. DHHS 21CFR (J).
Class1
Comply with class 1 laser safety.
4.1.3 Technical specifications
Table 4-2 lists technical specifications of the 1000BASE-X SFP optical interface.
Table 4-2 Technical specifications of the 1000BASE-X SFP optical interface
Parameter
Description
Connector
LC/PC
Optical interface properties
Depend on the SFP optical module.
Working mode
Full duplex
Compliant standard
IEEE 802.3
Supported network protocol
IP
