Raisecom ISCOM6820-GP User Manual

Raisecom
ISCOM6820-GP (A) Hardware Description
4 Pluggable optical modules
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
40
Table 4-8 Technical specifications of the Class C++ optical module
Parameter
Description
Model
GSFP-CLCDM-R
Transmission rate

Tx: 2.5 Gbit/s

Rx: 1.25 Gbit/s
Interface type
FC/PC
Max. transmission distance
60 km
Fiber mode
SMF
Central wavelength (Laser type)

Tx: 1490 nm (DFB)

Rx: 1310 nm (APD/TIA)
Tx optical power (BOL)
5.5–10 dBm
Tx optical power (EOL)
4.5–10 dBm
Extinction ratio
8.2 dB
Rx sensitivity
-31 dBm
Minimum overload point
-12 dBm
