4.3.3 Technical specifications
Table 4-6 lists technical specifications of the Class B+ optical module.
Table 4-6 Technical specifications of the Class B+ optical module
Parameter
Description
Model
GSFP-CLBDM-R
Transmission rate

Tx: 2.5 Gbit/s

Rx: 1.25 Gbit/s
Interface type
SC/PC
Max. transmission distance
20 km
Fiber mode
SMF
Central wavelength (Laser type)

Tx: 1490 nm (DFB)

Rx: 1310 nm (APD/TIA)
Tx optical power
1.5–5 dBm
Extinction ratio
8.2 dB
Rx sensitivity
-28 dBm
Minimum overload point
-8 dBm
Table 4-7 lists technical specifications of the Class C+ optical module.
Table 4-7 Technical specifications of the Class C+ optical module
Parameter
Description
Model
GSFP-CLCDM-R
Transmission rate

Tx: 2.5 Gbit/s

Rx: 1.25 Gbit/s
Interface type
SC/PC
Max. transmission distance
60 km
Fiber mode
SMF
Central wavelength (Laser type)

Tx: 1490 nm (DFB)

Rx: 1310 nm (APD/TIA)
Tx optical power
3–7 dBm
Extinction ratio
8.2 dB
Rx sensitivity
-30 dBm
Minimum overload point
-12 dBm
Table 4-8 lists technical specifications of the Class C++ optical module.
