SmarTrax & QuickTrax Operation Manual
56
A PPENDIX
S YSTEM D IAGRAMS
In this section you will find system diagrams for the following:
• Invicta 115/RGL 600 Universal/SmarTrax
• Viper/Invicta 115/RGL 600 Universal/SmarTrax
• Invicta 210 or 310/RGL 600 SmarTrax Guidance
• Viper/Invicta 210 or 310/RGL 500 SmarTrax Guidance
• RGL 600/SmarTrax/Non-Raven Receiver
• SmarTrax Decimeter Guidance
Each diagram also displays the components needed to correctly install the
system.
