User Guide of RFL-C20000TZ
51
SPW
Set Pulse Width
Send: ‘SPW 100\r’
Return: ‘SPW:100\r’
（Set pulse width as 100ms）
Other return values:
‘ERR: input Err\r’
（Input pulse width ＜0.0001）
‘ERR: Out of Range\r’
（Over maximum pulse width）
‘ERR: Duty Cycle too High\r’
‘ERR: Duty Cycle too Low\r’
‘SPW:100, Duty=100%\r’
SPRR
Set Pulse Repetition Rate
Send: ‘SPRR 1000\r’
Return: ‘SPRR：1000\r’
‘ERR: input Err\r’
‘ERR: Out of Range\r’
‘ERR: Duty Cycle too High\r’
‘ERR: Duty Cycle too Low\r’
‘SPW: 100, Duty=100%\r’
SDC
Set Diode Current (%)
The set value must be less than 100% and above
the minimum current setting value, which can be
set to 0. If the set value is greater than 100, the
default is input 100.
Send: ‘SDC 100\r’
Return: ‘SDC：100\r’
Other return values:
‘ERR: Input Err\r’
‘Laser is worked in AD Mode\r’
RCS
Read Current Set point
Send: ‘RCS\r’
Return: ‘RCS: 56.7\r’
(The current set value is 56.7 %)
RPRR
Read Pulse Repetition Rate (Hz)
Send: ‘RPRR\r’
Return: ‘RPRR:10\r’
(Repeat frequency is10Hz)
RBT
Read Board Temperature
Send: ‘RBT\r’
Return: ‘RBT:36.6\r’
RPW
Read Pulse Width (ms)
Send: ‘RPW\r’
Return: ‘RPW:5.5\r’
(pulse width is 5.5ms)
RCT
Read Laser Temperature
Send: ‘RCT\r’
Return: ‘RCT:34.5\r’
PERR
Reset Errors
Send: ‘PERR\r’
Return: ‘PERR\r’
SUT
Set Up Time (ms)
Send: ‘SUT 50\r’
Return: ‘SUT:50\r’
