Configurations
16
102-127108955 V1.1 64/ 102
→ Mech. end stop
▪ This feature can be configured if the option MS Mech.
door stop (102-127808234) is built-in or a door stop is
installed.
→ Disabled X Function deactivated
→ Active The door is held more firmly in the open position.
▪ Recommended for wind load or pressure fluctuations.
DOOR SYSTEM
→ Fire alarm system Specific adaptation to the requirements of the EN standards
for fire protection systems.
→ Disabled X Function disabled
→ Active Fulfilment of the requirements of the EN standards for fire pro-
tection systems. The door starts to move with less force.
→ Control In operation, this happens automatically. With the FPC 902, a
control mode can be imposed upon the drive for simulation
purposes or to divide a master / slave system.
→ Individual control X Single door, jumper J14 is in position M1
→ Master control Master of a master / slave system, jumper J14 is in position
M1
→ Slave control Slave of a master / slave system, jumper J14 is in position S1
→ Master interlock Master with interlock control, jumper J14 is in position M2
→ Slave interlock Slave with interlock control, jumper J14 is in position S2
