OVERVIEW
The REDMOTE is a remote camera control unit for the DSMC that attaches to the rear of the BRAIN or other
expansion module. When detached from the DSMC, the REDMOTE provides wireless camera control using the
proprietary REDLINK™ protocol. Whether attached or operating wirelessly, the REDMOTE provides access to all
necessary DSMC controls, including record start/stop, Shutter Speed, White Balance, ISO, and programmable
User Keys. The color LCD displays critical camera settings, including media and battery capacity, timecode and
clip name, lens data and exposure information.
The REDMOTE has a rechargeable Lithium Ion battery that automatically recharges when docked to the camera
or other module. It can also be recharged using the built-in USB 2.0 connector. Under typical operating
conditions, the REDMOTE provides up to eight (8) hours of battery life and supports wireless communication
at a range of approximately 50 ft. The REDMOTE supports 16 (0-15) wireless channels ranging from 2.4GHz to
2.4835GHz. The default channel is 0.
IMPORTANT: To operate properly, upgrade both REDMOTE and DSMC firmware to the most recent version.
REDMOTE
07
REDMOTE
OPERATION
