MIC-1, MIC-2 (MICROPHONE AUDIO)
The two (2) 3.5mm microphone jacks are microphone level analog audio inputs. Each jack has 2.4K ohm of
nominal impedance. For more information, go to “Record and Monitor Audio” on page 126.
 MIC-1: Ch1/Ch2
 MIC-2: Ch3/Ch4
MICROPHONE JACK
PIN SIGNAL DESCRIPTION DIRECTION
TIP IN + Mic Input (+48V Phantom Power) In
RING IN - Mic Input (+48V Phantom Power) In
SLEEVE GND Camera ground N/A
COMPATIBLE CABLE
 790-0229: XLR Microphone Cable (20")
SSD MODULE CONNECTORS
The connectors for the side SSD modules and the REAR SSD MODULE are described in the RED DSMC Media
Operation Guide, available at www.red.com/downloads.
