RED DSMC OPERATION GUIDE
COPYRIGHT © 2014 RED.COM, INC 955-0020_V5.2, REV-G | 175
HD-SDI OUT
A standard 75 ohm BNC connector provides the following output:
Broadcast specification HD-SDI video output (default mode is Clean)
Two (2) channels of embedded audio
Time of Day and Edge timecode
Record Tally flag
Clip name information (as SMPTE RP-188 VITC2 HANC metadata)
For more information, go to “Monitor” on page 61.
The HD-SDI output provides the formats described in the table below:
HD-SDI OUTPUT FORMATS
1
VIDEO FEED
2
FREQUENCY (HZ)
3
SMPTE STANDARD
720p 23.98, 24.00, 25.00, 29.97, 30.00, 50.00, 59.94 ST 292-1 (1.485 Gbps)
1080p 10-bit 4:2:2 23.98, 24.00, 25.00, 29.97, 30.00 ST 292-1 (1.485 Gbps)
1080p 10-bit 4:2:2 50.00, 59.94, 60.00 ST 424 (2.970 Gbps)
1. Ensure you select a frequency supported by your monitor.
2. The HD-SDI output is progressive scan (p); it does not support progressive segmented frame (PsF) or interlaced (i) scan formats.
3. The frequency options depend on project time base. If you have a non-drop frame project time base (such as 24.00), you can select
only non-drop frame frequencies. If you have a drop frame project time base (such as 23.98), you can select only drop frame frequencies.
75 OHM BNC CONNECTOR (HD-SDI)
PIN SIGNAL DESCRIPTION DIRECTION
Center HD-SDI SMPTE ST 424 HD-SDI Out
Shield/Screen GROUND Camera ground N/A
COMPATIBLE CABLE
790-0341: RED HD-SDI Cable (6')
