This chapter describes timecode, genlock, and multi-camera operations such as 3D and array setup.
TIMECODE
Timecode is a numeric sequence based on SMPTE 12M that aids in the management and synchronization of
footage and audio. Timecode is embedded in recorded RAW files as metadata and in HANC metadata provided
by the HD-SDI monitor output. The BRAIN can generate timecode on its own or can receive and sync timecode
generated by an external source.
Timecode displays in the lower right corner of the Live Action Area on the graphical user interface (GUI) and is
embedded as metadata. Timecode is represented as an eight (8) digit sequence (HH:MM:SS:FF), where:
HH: Hours
MM: Minutes
SS: Seconds
FF: Frames
NOTE: Timecode is most accurate and effective when coupled with genlock. For more information, go to
“Genlock” on page 146.
NOTE: The BRAIN cannot output internally generated timecode on its own. A Pro I/O Module or
4K Broadcast Module is required to output timecode generated by the BRAIN.
NOTE: For more information on HANC metadata, see HD-SDI HANC Metadata Information, available at www.
red.com/developers.
TIMECODE DISPLAY MODES
Time of Day (TOD): Displays the time of day (HH:MM:SS:FF). TOD timecode runs continuously and is not
affected by recording. TOD timecode can be synchronized with the Real-Time Clock (RTC) in the BRAIN.
Edge: Edge timecode is continuous between clips, meaning that when recording starts, timecode begins.
and when recording stops, timecode stops. Edge timecode default begins at 01:00:00:00, but can be
configured in the Media menu.
08
TIMECODE, GENLOCK,
MULTI-CAMERA SETUP
