RED DSMC OPERATION GUIDE: EPIC/SCARLET

REDMOTE LEDS

There are two (2) status LED indicators located above the rocker switch on the left side of the LCD display.

# REDMOTE LED COLOR/FLASHING DESCRIPTION

3 Power/Recording LED Red Camera startup; camera recording

4 Status/Connectivity LED Green Camera ready; REDMOTE connected

Green flashing Searching/Establishing communication

SOFT MENU BUTTONS (1-3)

There are three (3) Primary Soft Menu Buttons located below the left side of the REDMOTE LCD. These buttons

provide quick access to REDMOTE advanced operations.

 Button 1: Access Connect Menu.

 Button 2: Toggle between Local and Remote Modes.

 Button 3: Access Setup Menu.

REDMOTE CONTROL MODES

Press Button 2 to toggle between Remote Mode and Local Mode. The current mode displays on the REDMOTE

LCD, directly above the Primary Soft Menu Buttons. Use the Scroll Wheel and Directional Keys to navigate with

the cursor. For more information, go to “Navigation Group” on page 149.

 Local Mode: Navigate menus using the REDMOTE controls and display.

 Remote Mode: Navigate menus with REDMOTE controls, using an attached LCD, EVF, or other monitor as a

reference.

NOTE: When in Remote Mode, the current menu item does not display on the REDMOTE.

REDMOTE SETUP

The Setup Menu includes:

 Turn Wireless On/Off: Toggles the REDLINK wireless link on/off.

 Setup System: Provides access to REDMOTE settings.

 Setup Slot: Program the menu slots on the REDMOTE LCD.

SETUP SYSTEM

The Setup System Menu allows you to change REDMOTE settings and shows the MAC address and REDMOTE

firmware version.

The following adjustable settings are available:

 Brightness: LCD backlight intensity. Set the value to maximum for daylight visibility, or reduce it for standard

operation and prolonged battery life. Default is Maximum.

 Volume: Volume of the REDMOTE speaker. Default is Minimum.

 Auto Shutdown: Amount of inactivity time before the REDMOTE turns off automatically. Default is off.

NAVIGATION GROUP

Use the Navigation Group to navigate the DSMC menus and change settings.

 Scroll Wheel: Select and adjust the value of a selected setting.

 Directional Keys (D-Pad): Navigate menus.

 ENTER: Press ENTER to confirm a setting or access the selected menu.
