RED DSMC OPERATION GUIDE: EPIC/SCARLET

955-0020_V6.0, REV-J | 42

REPLACE THE HOOD SCOOP

REQUIRED TOOL: T8 TORX driver

The hood scoop on some EPIC-X and EPIC-M models extends beyond the rear plane of the BRAIN. RED offers

shorter hood scoops so that you can attach an LCD or other accessory to the mounting locations on the top

of the +1 Adaptor Module.

To replace DSMC fan hood scoop, follow the instructions below:

1. Turn off the BRAIN.

2. Remove the four (4) M3x0.5 x 6 mm screws holding the hood scoop using a T8 TORX driver.

3. Remove the hood scoop.

4. Position the replacement hood scoop on the BRAIN.

5. Align the hood scoop screw holes with the threaded holes.

6. Insert and tighten the four (4) M3x0.5 x 6 mm screws in a cross pattern (“X” pattern) using a T8 TORX driver.

DO NOT FULLY TIGHTEN.

7. Fully tighten the four (4) M3x0.5 x 6 mm cap screws evenly in a cross pattern (“X” pattern). DO NOT exceed

30 in-oz, or damage may occur.

WARNING: DO NOT OVERTIGHTEN.

Replace the hood

scoop
