Released for print production
Added Single Line Diagram; added Regional Setting notes; other minor edits
Updated; Re-organized; Rebranded
Spec Table Grid Interactive Port Rated Output Current AC 21.7A (was 24.5A)
Spec table updated; Firmware info added.
Wi-Fi compatibility update
Spec table updated- improved MPPT range; references to dual enclosures added.
P9 Added limitation due to not testing to AS/NZS 4777.2:2020 for multiple phase
combinations;
P24 Grid-side MCB info added: MCB Type C 40A; Backup CCT Sub-board RCD info added:
MCB/RCD Type A 30mA.
P29 BoS communications connection diagram redrawn; Ethernet cable assembly info
improved; DRED section reformatted.
P30 Relays section updated to match other documents.
P34 Additional instruction added "Plug Cable A into Fan Controller BATT port".
P49 Earth fault alarm information added.
P63 Reformat close-up and handover and move to inside back cover.
Building 1015, 80-120 Meiers Rd, Indooroopilly QLD 4068, Australia
customersupport@redbacktech.com
NOTICE OF COPYRIGHT
Installation
Manual Redback Smart Hybrid System ©2021 Redback Technologies.
All Rights Reserved. This work is copyright, apart from any use permitted under the Copyright Act 1968. No part may be
reproduced by any process, nor may any other exclusive right be exercised without the
permission of Redback Technologies
personal information provided to us only for warranty purposes. Without this information we will not be
able to process your warranty claim. If you require further information
about our privacy policy, please visit our website at
