GENERAL INFORMATION
ALL VERSIONS
Operating Temperature
Unconditioned without solar effects
-25°C to 60°C
Operating Temperature Derated Output
below 10°C and over 45°C
Operating Relative Humidity
0 - 95%
Operating Altitude
0 - 3000m
Protective Class
I
Ingress Protection Rating
IP65
AC Overvoltage Category
OVC III
DC Overvoltage Category
OVC II
Active Anti-islanding Method
Active Frequency Drift
Moisture Location Category
4K4H
External Environment Pollution Degree
Grade 1, 2 and 3
Inverter Topology
Non-isolated
Country of Origin
China
Demand Response Modes
DRM 0
Standby Self-Consumption
<13W
Noise Emissions
<30 dBm
Warranty
10 Years
EFFICIENCY
Maximum Efficiency
97.60%
Maximum Battery to Load Efficiency
94%
European Efficiency
97%
PHYSICAL DATA
Installed Weight (including SH5000, BE14000 and Batteries)
132-203kg
Dimensions (including PCE and BoS) (W x D x H)
518 x 360 x 840mm
Material
Aluminium
Finish
Sealed and powder coated
BE14000 SMART HYBRID BATTERY ENCLOSURE DATA
Number of Battery Units
2 to 4
Storage Capacity
4x 2.4kWh or 4x 3.55kWh
Battery System Model
US2000 or US3000
Maximum Capacity
14.2kWh
Nominal Voltage
DC 48V
Rated Current
DC 100A
Fan Specification
DC 48V / 0.13A x2
Protective Class
I
Ingress Protection Rating
IP54
Dimensions (W x D x H)
545x348x1125 mm
Material
Steel
Finish
Sealed and powder coated
