Redback SH5000 - Important safety instructions

6 Installation Manual - Redback Smart Hybrid System - v2.0
5.2 Inverter Status LEDs ........................................................................................................................... 49
5.3 EMS Status LEDs ................................................................................................................................ 52
5.4 SM3000 Energy meter diagnostics ..................................................................................................... 54
5.4.1 SM3000 features .................................................................................................................. 54
5.4.2 Energy meter/CT troubleshooting ....................................................................................... 54
5.5 Internet connection problems ........................................................................................................... 55
5.6 Inverter unexpected shutdown.......................................................................................................... 55
5.7 Reset Pylontech batteries .................................................................................................................. 56
Maintenance ........................................................................................................................................ 57
Specifications ....................................................................................................................................... 58
Related links and documents ................................................................................................................ 61
Close-up and handover ......................................................................................................................... 63
9.1 Close-up ............................................................................................................................................. 63
9.2 Handover ........................................................................................................................................... 63
Symbols used in this manual
SYMBOL
DEFINITION
SYMBOL
DEFINITION
LETHAL DANGER.
Risk of electrocution.
CAUTION!
Hazard to equipment
DANGER.
Risk of electrical shock.
EXPLOSION HAZARD
WARNING!
Hazard to human life
LIGHTNING STRIKE
HAZARD
WARNING! Burn hazard
SHARPS HAZARD
TIPPING HAZARD
. Do not leave unattended.
FIRE HAZARD
HEAVY LIFT
. Seek assistance.
DELAY.
Wait specified time.
INFORMATION. The information provided is important for
the correct installation, operation and or maintenance of
the equipment. Failure to follow the recommendations
could result in a warranty claim being denied.
PPE REQUIRED. Use appropriate
personal
protective equipment.
Symbols used elsewhere
SYMBOL
DEFINITION
SYMBOL
DEFINITION
HEAVY!
Bend knees to lift.
DELAY.
Wait specified time.
HEAVY!
Two-person lift required.
REFER TO DOCUMENTS.
PACKAGE MASS.
In kilograms.
Do not dispose as household waste.
THIS SIDE UP. The package must always be transported,
handled, and stored with arrows pointing up.
This product contains recyclable parts.
Dispose of correctly.
S
TACKING LIMIT. Stack packages six high or less.
FRAGILE. Handle with care.
Do not tip. Do not sling.
KEEP DRY The package/product must be protected from
excessive humidity and must be stored under cover.
