1. Turn the clamp knob on the left side of the clamp and pull the clamp and spacer block to take it out.
2. Fix a ring on flat surface of the rotation clamp. (Ring Outer Diameter Max.18mm)
3. Press the button and go to the expert menu mode.
4. Press button, and when menu appears on the LCD window, then press
and hold button until it beeps (more than 3 seconds) to run the menu.
5. Select the “4.Pointer/Rotary” then press and hold button until it beeps (more than 3 seconds) to run
the menu.
6. The tool draws cross (+) on the materials, and the laser pointer is turned on.
7. Use the direction key to move the laser pointer to the center of the cross, and press
and hold button for more than 2 seconds to save the settings.
8. Laser pointer moves closer to the material to accurately calibrate the laser pointer’s origin.
Move the laser pointer to the center of the cross by using the direction key on engraver,
and press and hold the button until it beeps (more than 3 seconds) to confirm that the setting is saved.
