6) How to Use the Clamp
◈ Multi performance Clamp
The holding part of clamp is step type, so set the clamp to the step to match the size and thickness are matched.
If you turn the clamp handle to the left, then the clamp will be loosed and turn it to the right, then the clamp will be
tightened.
When holding the materials by turning the clamp tightening handle, a mark may be left on the
materials.
◈ Adjusting the Height of the Clamp
The height of the clamp can be adjusted depending on the thickness of the materials or the type of clamps.
◈ How to use the pin
Pin holes on the clamp ensures easier holding of irregular shaped material.
◈ How to use the gradation on the clamp
Gradation on the clamp also helps easier positioning of material on the clamp.
