19
◈ How to attach the auxiliary jig
The auxiliary jig helps to hold thick materials like a beer bottle. As a pair, the Auxiliary jigs are holed by bolts
on each hole.
◈ Rotation Clamp(Chuck)
-Holding method for outer diameter engraving
Insert the ring until it clicks into the flat chuck finger and turn the chuck handle to hold the ring and not to allow it
come out or spin.
