REDT R&D MAGIC-70 - Technical Specifications

7
※Optional(Separately purchased)
Flat clamp
1EA
For holding material in place.
2) Specifications
Power supply
100~220V
Consumption
voltage
60W
Operating range
Flat : 140mm(X) x 100 mm(Y) x 38.5mm(Z)
Rotary: (X)
Cylinder outside diameter: Max.93mm
Cylinder inside diameter: Min.13mm~Max.93mm
Resolution
0.005mm (X,Y), 0.00125(Z)
Weight
31.15Kg
RPM
9,000~15,000 RPM
Transfer speed
1 – 36mm/sec (X,Y), 1 – 18mm/sec (Z)
Temperature
5 – 40 ºC
Humidity
10 - 90 %
Purposes
Metal engraving, Ring inner diameter, Ring outer diameter engraving,
Character cutting.
